Invacare Wheelchairs and Scooter Battery Guide
The table below contains a guide for Invacare Wheelchairs and Scooter batteries.
| Model | Battery |
|---|---|
| Arrow | (2ea.)12V 55AH (22NF) |
| Booster | (2ea.)12V 35AH (U1) |
| Cat | (2ea.)12V 35AH (U1) |
| Cat Basic | (2ea.)12V 35AH (U1) |
| Excel | (2ea.)12V 35AH (U1) |
| Excell FWD CAPT | (2ea.)12V 55AH (22NF) |
| Flyer | (2ea.)12V 35AH (U1) |
| Jaguar | (2ea.)12V 35AH (U1) |
| Lynx LX3 | (2ea.)12V 35AH (U1) |
| Lynx SX-3 | (2ea.)12V18AH |
| Lynx SX-3P | (2ea.)12V18AH |
| Panther LX-4 | (2ea.)12V 35AH (U1) |
| Panther MX-4 | (2ea.)12V 35AH (U1) |
| Power 9000(14" or less) | (2ea.)12V 35AH (U1) |
| Power 9000(16" or More) | (2ea.)12V 55AH (22NF) |
| Power Tiger | (2ea.)12V 55AH (22NF) |
| Pronto 250 | (2ea.)12V 35AH (U1) |
| Pronto R2 | (2ea.)12V 55AH (22NF) |
| P7E | (2ea.)12V 35AH (U1) |
| Rabbit | (2ea.)12V 35AH (U1) |
| Ranger X | (2ea.)12V 55AH (22NF) |
| Ranger MWD | (2ea.)12V 35AH (U1) |
| Ranger II CAPT | (2ea.)12V 55AH (22NF) |
| Ranger II RWD | (2ea.)12V 55AH (22NF) |
| Storm RX | (2ea.)12V 55AH (22NF) |
| Storm Torque | (2ea.)12V 55AH (22NF) |
| Torque | (2ea.)12V 55AH (22NF) |
| Tri Rolls | (2ea.)12V 35AH (U1) |
| Tri Scoot I & II | (2ea.)12V 35AH (U1) |
| Zoom 3, 200, 220 | (2ea.)12V12AH |
Quickie / Sunrise Wheelchairs and Scooter battery guide:
The table below contains a guide for Invacare Wheelchairs and Scooter batteries.
| Model | Battery |
|---|---|
| P100 | (2ea.)12V 35AH (U1) |
| P110* | (2ea.)12V 55AH (22NF) |
| P110* | (2ea.)12V 35AH (U1) |
| P190 | (2ea.)12V 35AH (U1) |
| P200 | (2ea.)12V75 AH |
| P210 | (2ea.)12V75 AH |
| P300 | (2ea.)12V75 AH |
| P320 | (2ea.)12V75 AH |
| P500 | (2ea.)12V 35AH (U1) |
| S 626 | (2ea.)12V 55AH (22NF) |
Merits battery guide:
The table below contains a guide for Invacare Wheelchairs and Scooter batteries.
| Model | Battery |
|---|---|
| MP3C, MPC3R | (2ea.)12V 35AH (U1) |
| MP3W | (2ea.)12V 35AH (U1) |
| MP1I Travel-Ease | (2ea.)12V 35AH (U1) |
| SP43/44 | (2ea.)12V 35AH (U1) |
| MP3F | (2ea.)12V 35AH (U1) |
| MP3CF | (2ea.)12V 35AH (U1) |
| MP3U | (2ea.)12V 35AH (U1) |
| MP3HD | (2ea.)12V75 AH |
| MP3R, Gemini | (2ea.)12V 55AH (22NF) |
| SP23 Pioneer | (2ea.)12V18AH |
| SP24 Pioneer | (2ea.)12V18AH |
| MP1I Travel-Ease | (2ea.)12V 35AH (U1) |
Pride Mobility Jazzy and Scooter battery guide:
The table below contains a guide for Invacare Wheelchairs and Scooter batteries.
| Model | Battery |
|---|---|
| Boxster | (2)12V 55Ah (22NF) |
| Celebrity | (2)12V 35Ah (U1) |
| Cyclone | (2)12V 35Ah (U1) |
| Dynamo | (2)12V 35Ah (U1) |
| Excel Series | (2)12V 35Ah (U1) |
| Go-Go | (2)12V12Ah |
| Hurricane | (2)12V40Ah |
| Jazzy 1101 | (2)12V 55Ah (22NF) |
| Jazzy 1103, 1113, 1143 | (2)12V 35Ah (U1) |
| Jazzy 1120 | (2)12V 75Ah (Group 24) |
| Jazzy 1115,1121,1122 | (2)12V 55Ah (22NF) |
| Jazzy 1133 | (2)12V 55Ah (22NF) |
| Jazzy 1150 | (2)12V 55Ah (22NF) |
| Jazzy 1170XL | (2)12V 55Ah (22NF) |
| Jazzy Pwt Seat | (2)12V 55Ah (22NF) |
| Laser Sports | (2)12V40Ah |
| Legend | (2)12V 35Ah (U1) |
| Maxima | (2)12V 55Ah (22NF) |
| Pride Jet 2 | (2)12V 55Ah (22NF) |
| Pride Jet 3 | (2)12V 35Ah (U1) |
| Pride Jet 10 | (2)12V 35Ah (U1) |
| Pride LX | (2)12V 35Ah (U1) |
| Quantum 1400,1420,1470 | (2)12V75 Ah |
| Quantum Blast 650 | (2)12V 55Ah (22NF) |
| Quantum Blast 850 | (2)12V 55Ah (22NF) |
| Quantum Blast HD | (2)12V 55Ah (22NF) |
| Quantum Blast Xtreme | (2)12V 55Ah (22NF) |
| Rally | (2)12V 35Ah (U1) |
| Revo | (2)12V18Ah |
| Shuttle | (2)12V 35Ah (U1) |
| SideKick | (2)12V 26Ah (U1) |
| SideKick II | (2)12V 35Ah (U1) |
| Sonic | (2)12V12Ah |
| Sundancer | (2)12V 35Ah (U1) |
| Victory | (2)12V 35Ah (U1) |
| Victory 2000 | (2)12V 35Ah (U1) |
| Victory XL | (2)12V 55Ah (22NF) |
| Wrangler | (2)12V90Ah |
| XL Models* | (2)12V 35Ah (U1) |
| XL Models* | (2)12V40Ah |
*Indicates different
battery configurations are possible. Please verify battery dimensions
before ordering.
