Harmar Highlander Portable VPL Vertical Platform Lift
Harmar Highlander Portable VPL Vertical Platform Lift
- Automatic, folding access ramp
- Available in AC and DC models
- Solid platform with non-skid surface for added safety
Our Price: $6,895.00
/
Description
Harmar Highlander Portable VPL Vertical Platform Lift
Harmars Residential Vertical Platform Lift (RPL) is a safe, smooth and economical solution to the barriers porches, staircases, decks and other elevation changes can create in and around a home.Designed from the ground up to be as cost-efficient as possible, the RPL is priced to be competitive with shorter units but built to accommodate most residential applications with ease.
Available in heights from 4 to 6 feet and for use indoors and out.
Features
- Automatic, folding access ramp
- Available in AC and DC models
- Solid platform with non-skid surface for added safety
- Solid 36 high guard panels
- Weather-resistant design for indoor and outdoor use
- Constant pressure, paddle switch controls with emergency stop button
- Sensitive safety pan on bottom of platform stops the lift if it meets an obstruction
- Lifting height4'-6' (53 to 77")
- Rated load600lbs (272 kg)
- DriveBelt driven Acme screw / 90 VDC 1/3 hp motor. Optional 24 VDC battery powered unit
- Power supply115 VAC 20 Amp grounded circuit
- Control circuit24 VAC (Low Voltage Controls)
- Platform36 x 48 with 36 high solid guard panels and automatic folding ramp
- Footprint50 x 70
- Speed10 fpm
- ControlsRocker switch w/emergency stop (key switch optional)
- Manual loweringProvided
- Safety design standardsASME A18.1, Section 5 Private Residence Vertical Platform Lifts
- Safety DesignCSA B44.1 / ASME 17.5 Elevator and Escalator Equipment
- Safety featuresSafety Pan, Final limit, Acme safety nut with monitor, Non-skid surface
- Warranty1-Year parts/ with Premium Protect Package* see details on waranty certificate
Technical Specs
Specifications
