Platinum 10L Oxygen Concentrator Bundle - 10 LPM
Our Oxygen Concentrator Specialists are available at 866-218-0902 M-F 9-5. Let us help you make a informed decision!
Our Price: $1,624.00
/
Description
Platinum 10L Oxygen Concentrator Bundle - 10 LPM
The Platinum 10 Oxygen Concentrator is an easy to use, reliable and attractive alternative to liquid systems. Offered in either the standard or with SensO2, the Platinum 10 Concentrator is available up to 10 LPM for high flow patients, is a pressure-based system and has a lifetime 4-way valve that is maintenance free and never needs servicing. Designed to be long lasting, the Invacare Platinum 10 is equipped with a durable one-piece hood and a top handle for the ease of mobility.Other features include a quick access door, with humidifier adapter storage, that allows users to get to both the compressor inlet and outlet HEPA filters and HomeFill compatibility. The alarms and safety systems within the Invacare Platinum include a battery-free power-loss alarm, a Sieve-GARD that monitors sieve performance, a compressor 35 psi pressure-relief valve, a low-flow alarm, and a SensO2 oxygen monitor (on the A13619 02 model only). Built to last, this concentrator provides lasting reliability.
Platinum 10 Oxygen Concentrator Features:
- Top handle for ease of mobility
- One-piece hood
- Lifetime 4-way valve is maintenance free
- Includes both compressor inlet and outlet HEPA filters
- Spring mounted compressor
- Quick access door houses humidifier adapter storage
- Battery-free power-loss alarm, low-flow alarm, Sieve-GARD monitors sieve performance
- Pressure-based system
- HomeFill II compatibility
- Simplified P.M. schedule
- Available in SensO2 and standard model
- Complies with EMC limits specified by IEC/EN 60601-1-2
Technical Specs
Specifications
Invacare Platinum 10 Oxygen Concentrator Specifications:
- Dimensions: 18 3/8"W x 26 3/8"H x 14 3/8"D
- Product weight: 54 lbs.
- Maximum outlet pressure: 9 +/- 0.5 PSI
- Rated current input: 4.7 amps average @ 5L/min.
- Sound level: 58 dB average
- Oxygen: Output- 94% to 87% at all flow rates
- Electrical: 120VAC +/- 10% (132VAC/108VAC); 60Hz
- Operating flow rate: 2 - 10 L/min
- Power: 585W
- Pressure: relief mechanism: 35 psi +/- 3.5 psi
- Filters: Cabinet, outlet HEPA, compressor inlet
