Smart FallGuard TL-2100E Economy Fall Monitor with Sensor Pad

Brand: Smart Caregiver Corporation  |  FSA Approved  |  1-Year Warranty

Universal Fall Monitor  |  Bed Pad, Chair Pad, Floor Mat & Seatbelt Compatible  |  Nurse Call Port  |  Caregiver Key Mode  |  Dual Audible & Visual Alert  |  Volume 0–90 dB  |  Pad Lost Light  |  3 Tone Options  |  9V Battery + Optional AC Adapter  |  By Smart Caregiver Corporation

A universal fall prevention monitor compatible with bed pressure pads, chair pressure pads, floor mats, and seatbelt monitors in a single unit — the TL-2100E adapts to multiple monitoring scenarios without requiring a separate monitor for each sensor type. A nurse call port connects the monitor directly to most existing facility nurse call systems, integrating fall alerts into the central nursing response workflow. Caregiver key mode deactivates the reset button on the monitor to prevent patients from silencing the alarm themselves. A large visual alert indicator supplements the audible alarm for visibility at a distance. Volume adjusts from fully off to 90 dB. A pad lost light illuminates if the sensor pad is disconnected or damaged. A status blink every 4 seconds confirms the system is active and functioning. Five configurations available with 90-day or 1-year sensor pads in bed, chair, and floor mat formats. FSA approved. 1-year warranty.

Select Your Configuration

All configurations include the TL-2100E monitor unit. The monitor is also compatible with additional Smart Caregiver seatbelt monitors and sensor pads purchased separately. Questions about which configuration is right for your patient? Call 1-866-218-0902

Sensor Placement by Type

Bed Pressure Pads: Place under the sheet. Position under the patient's shoulders to alert when the patient sits up; position under the lower back/buttocks to alert when the patient vacates the bed. The 5"×30" pad (EB90-SYS) is suited to smaller beds or targeted placement; the 20"×30" pad (EBW1-SYS) provides broader coverage across standard bed width.

Chair/Wheelchair Pressure Pads: Center the pad under the patient's buttocks on the seat surface. Mount the monitor out of reach of the patient — suitable mounting locations include the back of the wheelchair, back of headboard, wall mount, or under the bed.

Floor Mat (EFM7-SYS): Place the 24"×48" mat in a critical doorway, at the bedside, or in any location where stepped-on pressure should trigger an alert. The monitor mounts out of patient reach. Note: the status blink light does not function when using a floor mat configuration.

Seatbelt: Attaches to existing wheelchair seat screws via grommet holes on the seatbelt component. The alarm sounds when the seatbelt is unbuckled. Monitor mounts to the back of the wheelchair. (Seatbelt monitor component purchased separately.)

Key Features

• Universal sensor compatibility — one monitor works with bed pressure pads, chair pressure pads, floor mats, and seatbelt monitors; purchase additional sensor types to monitor the same patient across different environments without buying a new monitor
• Nurse call port — connects the TL-2100E directly to most existing nurse call systems in hospitals, SNFs, and assisted living facilities; fall alerts integrate into the central caregiver response workflow rather than sounding only at the bedside
• Caregiver key mode — deactivates the reset button on the front of the monitor; the monitor can only be reset by turning the on/off switch; prevents patients from silencing the alarm themselves after it activates
• Dual audible and visual alert — large visual indicator light allows caregiver to verify alarm state at a glance from a distance; audible alarm confirms activation for caregivers not in the line of sight of the light
• Volume adjustable 0–90 dB — volume can be reduced or muted completely for situations where a visual-only alert is preferable, or raised to 90 dB for environments where the caregiver is distant
• 3 tone options — selectable alarm tones to differentiate this alarm from others in the same facility or room
• Pad lost light — illuminates if the sensor pad is disconnected from the monitor or if the pad is damaged; confirms the monitoring circuit is complete during setup and alerts staff to a compromised sensor
• Status blink every 4 seconds — the monitor's status light blinks to confirm the pad is plugged in and pressure is on the pad; visual confirmation the system is actively monitoring without pressing any buttons
• T-shaped strain relief — protects the cord connection at the monitor from damage when cords are accidentally pulled; reduces cord disconnection and monitor damage in active care environments
• Low battery alert — audible and visual alert when battery is low or removed; prevents silent failure of monitoring between battery checks
• 9V battery with optional AC adapter — battery operation for flexibility; AC adapter available for continuous mains-powered operation without battery management
• Protective boot and adjustable strap — protective housing for the monitor unit; strap for mounting on wheelchairs, headboards, and rails
• 1-button reset — reset the alarm after responding to the patient without cycling the on/off switch (unless caregiver key mode is active)
• 90-day or 1-year sensor pads available — 90-day pads for shorter-term monitoring needs; 1-year pads for long-term residents or patients with ongoing fall risk
• FSA Approved | 1-year warranty | By Smart Caregiver Corporation

Clinical FAQs

What does the nurse call port do and which facility settings benefit from it?

The nurse call port is a standard connector on the TL-2100E that allows the fall monitor to plug directly into a facility's nurse call system infrastructure — the same wired network that bed controls, call buttons, and other monitoring devices connect to in hospitals, skilled nursing facilities, assisted living communities, and rehabilitation centers. When the fall monitor activates, the signal travels through the nurse call port to the nurse call system, which then alerts staff at the central nursing station or via pagers and wireless phones in addition to the bedside alarm. This integration means a fall alarm in one room is immediately visible across the nursing unit, not just to caregivers within earshot of the bedside alarm. It also creates a documented alarm event in facilities where the nurse call system logs alerts for compliance, falls prevention quality reporting, and risk management purposes. Facilities that have nurse call infrastructure and are managing patients on fall prevention protocols — post-surgical patients, dementia patients, fall-risk-scored patients in skilled nursing — benefit most from a monitor with nurse call integration. Home care settings and facilities without nurse call wiring use the TL-2100E with the audible/visual alarm only, without nurse call port connection.

What is caregiver key mode and when should it be used?

Caregiver key mode deactivates the physical reset button on the front of the TL-2100E monitor. When caregiver key mode is active, the only way to silence the alarm is by using the on/off switch on the side of the monitor — a less intuitive action than pressing a clearly labeled reset button. This makes it significantly more difficult for a cognitively impaired patient to silence the alarm themselves after it activates. Without caregiver key mode, a patient who hears the alarm and understands that the button stops it could press the button — silencing the alarm before staff respond, leaving the patient unmonitored for the duration of their unassisted transfer. Caregiver key mode should be activated for any patient with sufficient cognitive awareness to locate and press a button on the alarm unit but insufficient judgment to remain in bed safely without supervision — a common presentation in early to moderate dementia, post-stroke frontal lobe impairment, or delirium. For patients who are cognitively intact and actively participate in their fall prevention plan, caregiver key mode may be unnecessary. For patients with dementia, confusion, or impulsive behavior, it is an important safeguard against alarm defeat.

How do I choose between the bed pad, chair pad, and floor mat configurations?

The configuration choice depends on the primary monitoring scenario for the patient. Bed pad configurations (EB90-SYS or EBW1-SYS) are appropriate when the primary fall risk is unsupervised bed exit — the patient is confined to or spending most of their time in bed, and unassisted rising is the behavior to detect. The 5"×30" bed pad places under a targeted area of the mattress for specific-zone detection; the 20"×30" pad provides broader mattress coverage. Position under shoulders for sit-up detection or under the lower back/buttocks for vacating-the-bed detection. Chair pad configurations (EC90-SYS or EC1-SYS) are appropriate for patients in wheelchairs or recliner chairs who are monitored for unassisted standing or forward transfer attempts. The 10"×15" pad centers under the buttocks on the seat surface. The Silver Lining chair pad (EC1-SYS) provides a 1-year pad life for long-term chair-based monitoring. Floor mat configuration (EFM7-SYS) serves a different detection purpose: rather than detecting when the patient leaves a surface, it detects when the patient reaches the floor — placed at the bedside to detect if a patient has already risen and is walking unsteadily, or placed at a doorway to monitor for unauthorized room egress. The floor mat is particularly useful for ambulatory patients with dementia who are monitored for wandering, and for patients at risk of nighttime fall at the bedside after they have already transferred out of bed. For comprehensive monitoring, a bed pad and floor mat can be used together with separate monitors, covering both the bed exit event and the subsequent floor contact.

Questions about TL-2100E configuration selection, nurse call system compatibility, or caregiver key mode? Call our product specialists: 1-866-218-0902  |  Mon–Fri 9am–5pm, Sat 9am–3pm EST
